20.1.5 CS-Z50TKR CU-Z50TKR
3.000
3.500
4.000
4.500
5.000
5.500
6.000
6.500
16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46
Current (A)
Outdoor Temperature （℃）
230V 240V
1.000
1.020
1.040
1.060
1.080
1.100
1.120
145.000
148.000
151.000
154.000
157.000
160.000
163.000
16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46
Lo Pressure (MPa)
Lo Pressure (Psi)
Outdoor Temperature （℃）
230V 240V
13.500
14.000
14.500
15.000
15.500
16.000
16.500
17.000
16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46
Indoor
D
i
scharge
Air Temperature (℃)
Outdoor Temperature （℃）
230V 240V
230V 240V
16 3.360 3.160
25 4.070 3.870
35 5.300 5.100
46 6.170 5.970
16 1.015 147.213
25 1.047 151.855
35 1.069 155.045
46 1.112 161.282
16
25
35
46
Lo Pressure
(MPa)
Lo Pressure
(Psi)
Outdoor
Temperature (°C)
Current (A)
14.660
15.500
16.520
Outdoor
Temperature (°C)
Outdoor
Temperature (°C)
Indoor Discharge
Air Temperature (°C)
13.920
