40
11. Printed Circuit Board
11.1 Indoor Unit
11.1.1 Main Printed Circuit Board
CN-FM
AC306
RY-PWR
G301
AC304
JP1 (Random Auto Restart Enable/Disable) CN-DISP
AC303
SW01
CN-CNT
CN-STM1
CN-STM2
CN-STM3
CN-RMT
CN-CLN
CN-TH
CN-MSENS
CN-RCV
