Page #19 background image
19
Indoor
Model CS-Z71TKR CS-Z80TKR
POS (EAN) 5025232871513 5025232871520
Outdoor
Model CU-Z71TKR CU-Z80TKR
POS (EAN) 5025232871704 5025232871711
Performance Test Condition AS AS
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 240 230 240
Min. Mid. Max. Min. Mid. Max. Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 1.70 7.10 8.10 1.70 7.10 8.10 2.30 8.00 9.00 2.30 8.00 9.00
BTU/h 5800 24200 27600 5800 24200 27600 7840 27300 30700 7840 27300 30700
Kcal/h 1460 6110 6970 1460 6110 6970 1980 6880 7740 1980 6880 7740
Running Current A - 8.8 - - 8.6 - - 11.2 - - 10.9 -
Input Power W 430 1.97k 2.48k 430 1.97k 2.48k 460 2.32k 2.82k 460 2.32k 2.82k
EER / EER CLASS W/W 3.95
3.60 /
2.5
3.27 3.95
3.60 /
2.5
3.27 5.00
3.45 /
2.0
3.19 5.00
3.45 /
2.0
3.19
EER
BTU/hW 13.49 12.28 11.13 13.49 12.28 11.13 17.04 11.77 10.89 17.04 11.77 10.89
Kcal/hW 3.40 3.10 2.81 3.40 3.10 2.81 4.30 2.97 2.74 4.30 2.97 2.74
Power Factor % - 97 - - 95 - - 90 - - 89 -
Indoor Noise (H / L / QLo)
dB-A 49 / 37 / 34 49 / 37 / 34 51 / 38 / 35 51 / 38 / 35
Power Level dB 65 / 53 / 50 65 / 53 / 50 67 / 54 / 51 67 / 54 / 51
Outdoor Noise (H / L / QLo)
dB-A 54 / - / 49 54 / - / 49 55 / - / 50 55 / - / 50
Power Level dB 68 / - / 63 68 / - / 63 69 / - / 64 69 / - / 64
Heating
Capacity
kW 1.70 8.00 9.90 1.70 8.00 9.90 2.20 9.00 11.00 2.20 9.00 11.00
BTU/h 5800 27300 33800 5800 27300 33800 7500 30700 37500 7500 30700 37500
Kcal/h 1460 6880 8510 1460 6880 8510 1890 7740 9460 1890 7740 9460
Running Current A - 9.4 - - 9.2 - - 11.6 - - 11.3 -
Input Power W 380 2.11k 3.00k 380 2.11k 3.00k 500 2.41k 3.30k 500 2.41k 3.30k
COP / COP CLASS W/W 4.47
3.79 /
3.0
3.30 4.47
3.79 /
3.0
3.30 4.40
3.73 /
2.5
3.33 4.40
3.73 /
2.5
3.33
COP
BTU/hW 15.26 12.94 11.27 15.26 12.94 11.27 15.00 12.74 11.36 15.00 12.74 11.36
Kcal/hW 3.84 3.26 2.84 3.84 3.26 2.84 3.78 3.21 2.87 3.78 3.21 2.87
Power Factor % - 98 - - 96 - - 90 - - 89 -
Indoor Noise (H / L / QLo)
dB-A 49 / 37 / 34 49 / 37 / 34 50 / 38 / 35 50 / 38 / 35
Power Level dB 65 / 53 / 50 65 / 53 / 50 66 / 54 / 51 66 / 54 / 51
Outdoor Noise (H / L / QLo)
dB-A 54 / - / 49 54 / - / 49 55 / - / 50 55 / - / 50
Power Level dB 68 / - / 63 68 / - / 63 69 / - / 64 69 / - / 64
H2
Capacity kW 6.2 7.4
Input Power kW 2.10 2.65
COP W/W 2.95 2.79
Powerful Heat
Capacity kW 9.90 11.00
Input Power kW 3.00 3.30
COP W/W 3.30 3.33
Max Current (A) / Max Input Power (W) 15.0 / 3.33k 15.4 / 3.50k
Starting Current (A) 9.4 11.6
Compressor
Type Hermetic Motor / Rotary Hermetic Motor / Rotary
Motor Type Brushless (4 poles) Brushless (4 poles)
Output Power W 1.70k 1.70k
