13
English
Energy saving temperature setting
You may save energy when operating the unit within the recommended temperature range.
HEAT : 20.0 °C ~ 24.0 °C / 68 °F ~ 75 °F.
COOL: 26.0 °C ~ 28.0 °C / 79 °F ~ 82 °F.
Air fl ow direction
In COOL/DRY mode:
The horizontal fl ap swings up/down automatically.
Once the temperature is achieved, the horizontal fl ap is fi xed at upper position.
In HEAT mode:
The horizontal fl ap fi xed at the predetermined position.
The vertical fl ap swings left/right when the temperature rises.
In COOL/DRY mode:
The horizontal fl ap swings up/down automatically.
In HEAT mode:
The horizontal fl ap is fi xed to upper position when discharge air temperature is cold.
The horizontal fl ap swings up-down automatically when discharge air temperature is warm.
Auto restart control
When power is resumed after a power failure, the operation will restart automatically with the
last operation mode and airfl ow direction.
• This control is not applicable when TIMER is set.
To Learn More...
Operation mode
AUTO : The POWER indicator blinks at the initial stage.
• The unit will select an operation mode every 10 minutes depending on the setting
and room temperature.
HEAT : The POWER indicator blinks at the initial stage. The unit will take some time to
warm up.
COOL : Provides effi cient comfort cooling to suit your needs.
DRY : Operates at low fan speed for a gentle cooling operation.
Operating conditions
Use this air conditioner in the temperature range indicated in the table.
Temperature
°C (°F)
Indoor Outdoor
DBT WBT DBT WBT
COOL
Max. 32 (89.6) 23 (73.4) 43 (109.4) 26 (78.8)
Min. 16 (60.8) 11 (51.8) -25 (-13) -
HEAT
Max. 30 (86.0) - 24 (75.2) 18 (64.4)
Min. 16 (60.8) - -15 (5.0) -
DBT: Dry bulb temperature, WBT: Wet bulb temperature
Main Menu / To Learn More...
