Panasonic CT-2707DF - Parts List

REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-13-
042-02
PARTS LIST
Parts List
REF
NO.
PART NO. DESCRIPTION
CAPRISTORS
CRA801 TP00842-51 TAPING GAP TERMINAL
CRA802 TP00842-51 TAPING GAP TERMINAL
CAPACITORS
C001 ECA1CM470B CAP,E 47UF/16V
C002 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C003 ECA1HM4R7B CAP,E 4.7UF-50V
C005 ECA1CM470B CAP,E 47UF/16V
C006 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C008 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C009 TCJ2VC1H560J CAP,C 56PF-J-50V
C010 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C011 ECA0JM331B
CAP,E 330UF-6.3V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C013 ECA0JM101B CAP,E 100UF-6.3V
C016 TCJ2VC1H101J CAP,C 100PF-J-50V
C017 TCJ2VC1H270J CAP,C 27PF-J-50V
C018 TCJ2VC1H270J CAP,C 27PF-J-50V
C020 ECA0JM102B
CAP,E 1000UF-6.3V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
C020 ECA0JM222B
CAP,E 2200UF-6.3V
CT-36D12DF/DUF CT-36D32F/UF
C020 ECA0JM331B
CAP,E 330UF-6.3V
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
C021 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C022 ECA1EM471B CAP,E 470UF-25V
C024 ECA1HM4R7B CAP,E 4.7UF-50V
C025 ECA1HM010B CAP,E 1UF-50V
C026 ECA1HM010B CAP,E 1UF-50V
C032 ECA1CM331B CAP,E 330UF-16V
C033 TCJ2VC1H680J CAP,C 68PF-J-50V
C034 TCJ2VC1H680J CAP,C 68PF-J-50V
C043 ECA1HM2R2B CAP,E 2.2UF-50V
C044 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C047 ECA0JM102B CAP,E 1000UF-6.3V
C048 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C201 ECJ2VB1C104K CAP,C .1UF-K-16V
C224 ECJ2VB1C104K CAP,C .1UF-K-16V
C225 ECJ2VB1C104K CAP,C .1UF-K-16V
C226 ECJ2VB1C104K CAP,C .1UF-K-16V
C301 ECJ2VB1C104K CAP,C .1UF-K-16V
C302 ECJ2VB1C104K CAP,C .1UF-K-16V
C303 ECJ2VB1C104K CAP,C .1UF-K-16V
C307 ECA1HM0R1B
CAP,E 0.1UF/50V
CT-36D12DF/DUF CT-36D32F/UF
C309 TCJ2VC1H390J
CAP,C 39PF-J-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
C310 TCJ2VC1H390J CAP,C 39PF-J-50V
C314 EEANA1E1R0B
CAP,E 1.0UF-25V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
C315 EEANA1E1R0B CAP,E 1.0UF-25V
C320 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C321 TCJ2VB1H103K CAP,C .01UF-K-50V
C322 TCJ2VB1H103K CAP,C .01UF-K-50V
C323 TCJ2VB1H103K CAP,C .01UF-K-50V
C324 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C330 ECA1AM101B CAP,E 100UF-10V
C331 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C337 ECA1HM2R2B CAP,E 2.2UF-50V
C342 ECA1HM010B CAP,E 1UF-50V
C351 ECKW3D102KBN
CAP,C .001UF-K-2KVDC
CT-36D12DF/DUF CT-36D32F/UF
C351 TACCW331T50V
CAP,C 330PF/50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
C352 EEANA1E1R0B
CAP,E 1.0UF-25V CT-36D12DF/DUF CT-
36D32F/UF
C352 TACCW331T50V
CAP,C 330PF/50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
C353 TACCW331T50V
CAP,C 330PF/50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
C353 TACCW821T50V
CAP,C 820PF/50V
CT-36D12DF/DUF CT-36D32F/UF
C354 ECKW3D102KBN
CAP,C .001UF-K-2KVDC
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
C354 TACCW821T50V
CAP,C 820PF/50V
CT-36D12DF/DUF CT-36D32F/UF
C355 TACCW821T50V
CAP,C 820PF/50V
CT-36D12DF/DUF CT-36D32F/UF
C356 ECA1CM100B
CAP,E 10UF-16V
CT-36D12DF/DUF CT-36D32F/UF
C357 ECKR2H821KB5
CAP,C 820PF-K-500V
CT-36D12DF/DUF CT-36D32F/UF
C357 EEANA1E1R0B
CAP,E 1.0UF-25V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
C358 TACCW101T50V
CAP,C 100PF/50V
CT-36D12DF/DUF CT-36D32F/UF
C359 TACCW101T50V
CAP,C 100PF/50V
CT-36D12DF/DUF CT-36D32F/UF
REF
NO.
PART NO. DESCRIPTION
