Instructional Flow Chart for Serviceman Mode - Continued
Adj.
needed?
CUT-OFF ADJUSTMENTS.
C ITEMS.
A
N
Y
PINCUSHION ADJUSTMENTS.
D ITEMS.
Adj.
needed?
N
Y
MTS ADJUSTMENTS.
M ITEMS.
Adj.
needed?
N
Y
POWER
(ON REMOTE)
POWER
(ON REMOTE)
POWER
(ON REMOTE)
ON REMOTE CONTROL TO
SELECT ADJUSTMENT
ON REMOTE TO ADJUST
THE LEVEL
CH
VOL
VOL
ON REMOTE CONTROL TO
SELECT ADJUSTMENT
ON REMOTE TO ADJUST
THE LEVEL
CH
VOL
VOL
ON REMOTE CONTROL TO
SELECT ADJUSTMENT
ON REMOTE TO ADJUST
THE LEVEL
CH
VOL
VOL
B
IMPORTANT NOTE:
Always Exit the Serviceman
Mode Following Adjustments.
Figure 17. Flow Chart for Serviceman Mode (cont).
