Panasonic CT-27D10B - Parts List

- 36 -
Parts List
REPLACEMENT PARTS LIST
Models: CT-27D10B, CT-27D10UB & CT-27D10DB
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
074-00
PARTS LIST
REF NO. PART NO. DESCRIPTION
CAPRISTORS
CRA801 TP00842-51 TAPING GAP TERMINAL
CRA802 TP00842-51 TAPING GAP TERMINAL
CAPACITORS
C001 ECA1CM470 CAP,E 47UF/16V
C002 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C003 ECA1HM4R7 CAP,E 4.7UF/50V
C005 ECA1CM470 CAP,E 47UF/16V
C006 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C008 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C010 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C013 ECA0JM101 CAP,E 100UF/6.3V
C016 ECJ2VC1H101J CAP,C 100PF-J-50V
C017 ECJ2VC1H270J CAP,C 27PF-J-50V
C018 ECJ2VC1H270J CAP,C 27PF-J-50V
C020 ECA0JM331 CAP,E 330UF/6.3V
C021 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C022 ECA1CM471 CAP,E 470UF/16V
C024 ECA1HM4R7 CAP,E 4.7UF/50V
C025 ECA1HM010 CAP,E 1.0UF/50V
C026 ECA1HM010 CAP,E 1.0UF/50V
C032 ECA1CM331 CAP,E 330UF/16V
C033 ECJ2VC1H680J CAP,C 68PF-J-50V
C034 ECJ2VC1H680J CAP,C 68PF-J-50V
C036 ECJ2VC1H101J CAP,C 100PF-J-50V
C043 ECA1HM2R2 CAP,E 2.2UF/50V
C044 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C047 ECA0JM102 CAP,E 1000UF/6.3V
C048 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C201 ECJ2VB1C104K CAP,C .1UF-I-16V
C224 ECJ2VB1C104K CAP,C .1UF-I-16V
C225 ECJ2VB1C104K CAP,C .1UF-I-16V
C226 ECJ2VB1C104K CAP,C .1UF-I-16V
C301 ECJ2VB1C104K CAP,C .1UF-I-16V
C302 ECJ2VB1C104K CAP,C .1UF-I-16V
C303 ECJ2VB1C104K CAP,C .1UF-I-16V
C307 ECA1HM0R1 CAP,E 0.1UF/50V
C309 ECJ2VC1H390J CAP,C 39PF-J-50V
C310 ECJ2VC1H390J CAP,C 39PF-J-50V
C314 EEANA1E1R0B CAP,E 1.0UF-25V
C315 EEANA1E1R0B CAP,E 1.0UF-25V
C320 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C321 ECJ2VB1H103K CAP,C .01UF-K-50V
C322 ECJ2VB1H103K CAP,C .01UF-K-50V
C323 ECJ2VB1H103K CAP,C .01UF-K-50V
C324 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C330 ECA1AM101 CAP,E 100UF/10V
C331 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C337 ECA1HM2R2 CAP,E 2.2UF/50V
C342 ECA1HM010 CAP,E 1.0UF/50V
C351 TACCW331T50V CAP,C 330PF/50V
C352 TACCW331T50V CAP,C 330PF/50V
C353 TACCW331T50V CAP,C 330PF/50V
C354 ECKD3D102KB CAP,C .001UF-K-2KV
C357 EEANA1E1R0B CAP,E 1.0UF-25V
C401 ECJ2VB1C104K CAP,C .1UF-I-16V
C402 ECA1HM470 CAP,E 47UF/50V
C403 ECA1HM010 CAP,E 1.0UF/50V
C404 ECA1HM010 CAP,E 1.0UF/50V
C405 ECSF1EE105 CAP,T 1.0UF/25V
C407 ECA1HM470 CAP,E 47UF/50V
C409 ECJ2VC1H101J CAP,C 100PF-J-50V
C415 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C451 ECA1HM2R2 CAP,E 2.2UF/50V
C452 ECQB1H473JM CAP,P .047UF-J-50V
C453 ECA1VM471 CAP,E 470UF/35V
C454 ECA1VM221 CAP,E 220UF/35V
C455 ECA1VM222 CAP,E 2200UF/35V
C456 ECCF1H020CC CAP,C 2PF-C-50V
C457 ECJ2VB1C104K CAP,C .1UF-I-16V
C458 ECA1CM101 CAP,E 100UF/16V
C459 ECQM1104JZ CAP,P .1UF-J-100V
C502 ECA1CM221 CAP,E 220UF/16V
C503 ECJ2VC1H221J CAP,C 220PF-J-50V
C504 ECQB1H222JM CAP,P 2200PF-J-50V
C505 ECJ2VC1H180J CAP,C 18PF-J-50V
C506 ECA1AM101 CAP,E 100UF/10V
C507 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C508 ECJ2VC1H102J CAP,C .001UF-J-50V
C510 ECCD2H100D CAP,C 10PF-D-500V
C511 ECKD2H821KB CAP,C 820PF-K-500V
C512 ECKD2H101KB CAP,C 100PF-K-500V
C514 ECA1HMR22 CAP,E .22UF/50V
C515 ECJ2VC1H222J CAP,C .0022UF-J-50V
C516 ECJ2VC1H391J CAP,C 390PF-J-50V
C517 ECJ2VC1H221J CAP,C 220PF-J-50V
C518 ECJ2VC1H151J CAP,C 150PF-J-50V
C531 ECA1EM220 CAP,E 22UF/25V
C551 ECA1VM331 CAP,E 330UF/35V
C552 ECA1CM331 CAP,E 330UF/16V
C553 ECA1CM331 CAP,E 330UF/16V
C554 ECKD2H561KB CAP,C 560PF-K-500V
C555 ECA2EM220 CAP,E 22UF-250V
C556 ECA1CM102 CAP,E 1000UF/16V
C557 ECKD2H102KB CAP,C .001UF-K-500V
C558 ECA1CM221 CAP,E 220UF/16V
C560 ECEA1HN2R2U CAP,E 2.2UF/50V
C561 ECKD2H561KB CAP,C 560PF-K-500V
C562 ECKD2H561KB CAP,C 560PF-K-500V
C563 ECWH12H822JS CAP,P .0082UF-J-1.2KV
REF NO. PART NO. DESCRIPTION
