- 30 -
Parts List
REPLACEMENT PARTS LIST
Models: CT-32G6E/CE/UE
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
094-01
PARTS LIST
C801 ECKWAE472ZED CAP,C 4700PF-Z-500V
C802 ECKWAE472ZED CAP,C 4700PF-Z-500V
C803 ECKWAE472ZED CAP,C 4700PF-Z-500V
C805 EC0S2DA471BB CAP,E 470UF/160V
C806 ECQM4103KZW CAP,P .01UF-K-400V
C807 ECKR3A821KBP CAP,C 820PF-K-1KV
C808 ECA1VM101B CAP,E 100UF-35V
C809 ECKR1H101KB5 CAP,C 100PF-K-50V
C810 ECKR1H471KB5 CAP,C 470PF-K-50V
C812 ECQU2A224MVA CAP,P .22UF-M-250VAC
C813 ECQU2A153MVA CAP,P .015UF-M-250VAC
C814 ECQU2A153MVA CAP,P .015UF-M-250VAC
C820 ECA1CM101B CAP,E 100UF/16V
C821 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C822 ECKR3A221KBP CAP,C 220PF-K-1KV
C823 ECA1HM471B CAP,E 470UF-50V
C824 ECKR3A471KBP CAP,C 470PF-K-1KV
C825 EEUMG2C221S CAP,E 220UF-160V
C826 ECKR3A471KBP CAP,C 470PF-K-1KV
C827 ECA1CM221B CAP,E 220UF-16V
C828 ECA160V33UE CAP,E 33UF/160V
C2201 ECA1HM4R7B CAP,E 4.7UF-50V
C2202 ECA1HM2R2B CAP,E 2.2UF-50V
C2203 ECA1HM4R7B CAP,E 4.7UF-50V
C2204 AP106K016CAE CAP,T 10UF/16V
C2205 ECA1HMR33B CAP,E .33UF-50V
C2206 ECQB1H223JM3 CAP,P .022UF-J-50V
C2207 AP335K016CAE CAP,T 3.3UF/16V
C2208 ECJ2VB1C104K CAP,C .1UF-K-16V
C2209 ECJ2VB1C104K CAP,C .1UF-K-16V
C2210 ECJ2VB1C104K CAP,C .1UF-K-16V
C2212 ECQB1H473JM3 CAP,P .047UF-J-50V
C2213 ECA1HMR47B CAP,E .47UF-50V
C2214 ECA1CM101B CAP,E 100UF/16V
C2215 EEANA1E100B CAP,E 10UF-25V
C2216 ECJ2VC1H100D CAP,C 10PF-D-50V
C2301 ECA1VM102E CAP,E 1000UF-35V
C2302 ECEA1HN010UB CAP,E 1UF/50V
C2303 ECA1EM101B CAP,E 100UF-25V
C2304 ECA1EM100B CAP,E 10UF-25V
C2307 ECA1CM102B CAP,E 1000UF/16V
C2311 ECA1VM102E CAP,E 1000UF-35V
C2312 ECEA1HN010UB CAP,E 1UF/50V
C2313 ECA1EM101B CAP,E 100UF-25V
C2314 ECA1CM100B CAP,E 10UF-16V
C2317 ECA1CM102B CAP,E 1000UF/16V
C2320 ECA1CM100B CAP,E 10UF-16V
C2330 ECA1CM100B CAP,E 10UF-16V
C2350 ECA1HM4R7B CAP,E 4.7UF-50V
C3001 ECA1HM0R1B CAP,E 0.1UF/50V
C3012 ECA1HM010B CAP,E 1UF-50V
REF NO. PART NO. DESCRIPTION
C3018 ECA1HM010B CAP,E 1UF-50V
C3050 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3051 ECJ2VF1H103Z CAP,C .01UF-Z-50V
DIODES
D002 MA165TA5VT DIODE, SWITCHING
D006 MA4330HTA DIODE
D052 MA4068MTA DIODE, ZENER
D451 ERA15-01V3 DIODE, RECTIFIER
D452 MA4047MTA DIODE
D453 MA165TA5VT DIODE, SWITCHING
D454 MA165TA5VT DIODE, SWITCHING
D502 MA4047MTA DIODE
D531 AS01V0 DIODE
D551 D1NL20UV70 DIODE
D554 AU02V0 DIODE
D558 RS3FS DIODE
D559 BYD33G-113 DIODE
D561 AU02V0 DIODE
D571 MA165TA5VT DIODE, SWITCHING
D606 MA165TA5VT DIODE, SWITCHING
D607 MA152KTX DIODE
D608 MA152KTX DIODE
D609 MA152KTX DIODE
D751 MA2360B DIODE
D801 D3SBA60-4103 DIODE
D806 TAP4GA0006 DIODE (THERMISTOR)
D808 SARS01V1 DIODE
D809 AG01V0 DIODE
D810 AG01V0 DIODE
D811 AG01V0 DIODE
D812 MA4068MTA DIODE, ZENER
D820 MA165TA5VT DIODE, SWITCHING
D821 MA4047HTA DIODE
D822 RN1ZLF-B1 DIODE
D823 S3L60P154004 DIODE
D824 D1NL20UV70 DIODE
D2350 MA4068MTA DIODE, ZENER
D2351 MA165TA5VT DIODE, SWITCHING
D2352 MA165TA5VT DIODE, SWITCHING
D2353 MA165TA5VT DIODE, SWITCHING
D2354 MA4091MTA DIODE
D3001 MA3110MTX DIODE, ZENER
D3003 MA3110MTX DIODE, ZENER
D3004 MA3110MTX DIODE, ZENER
D3005 MA3110MTX DIODE, ZENER
D3006 MA3110MTX DIODE, ZENER
FUSES
F801 XBA2A00101 FUSE 6.3A 125V
INTEGRATED CIRCUITS
IC001 M65580MAP101 IC, MPU/VCJ
IC002 TVR2AJ092 IC, EEPROM
REF NO. PART NO. DESCRIPTION
To Next Page
