Panasonic CT-32G6E - Service Mode Adjustments

- 47 -
SERVICE MODE (ELECTRONIC CONTROL)
SERVICE ADJUSTMENT VALUES
Model _____________________________________________ Ser #_____________ Date_________________
Note: Record the original settings PRIOR to modifying the registers.
Mode
Service
Adjustment
Adjustment
Range
Def.
Val.
Original
Value
New
Value
Sub Adjustments
B0
SUB-COLOR
0 ~ 127 33
B1
SUB-TINT
0 ~ 127 36
B2
SUB-
BRIGHTNESS
0 ~ 255 127
B3
SUB-CONTRAST
0 ~ 127 20
B4
R OFFSET
N/A 0
FACTORY PRESET
B5
YNR
N/A 0
FACTORY PRESET
B6
YNR LIM
N/A 0
FACTORY PRESET
Cut-Off Adjustments
C0
CUT-OFF R
0 ~ 255
0 ~ 255
0
255
C1
CUT-OFF G
0 ~ 255
0 ~ 255
0
255
C2
CUT-OFF B
0 ~ 255
0 ~ 255
0
255
C3
R DRIVE
0 ~ 127 80
C4
G DRIVE
0 ~ 127 80
C5
B DRIVE
0 ~ 127 80
C6
V SIZE
0 ~ 255 127
C7
NOT USED
-- --
NOT USED
C8
NOT USED
-- --
NOT USED
C9
HORIZONTAL
CENTER
0 ~ 31 16
CA
ACL
0 ~ 1 1
CB
HHS
0 ~ 7 0
CC
OSD SHIFT
N/A 88
FACTORY PRESET
CD
ACL-REF
N/A 74
FACTORY PRESET
CE
ACL-REF
N/A 64
FACTORY PRESET
CF
ACL-REF
N/A 48
FACTORY PRESET
C10
ACL-REF
N/A 40
FACTORY PRESET
C11
ACL-REF
N/A 31
FACTORY PRESET
C12
ACL-REF
N/A 20
FACTORY PRESET
C13
ACL-COEFF
N/A 124
FACTORY PRESET
Mode
Service
Adjustment
Adjustment
Range
Def.
Val.
Original
Value
New
Value
Cut-Off Adjustments, Cont.
C14
ACL-COEFF
N/A 117
FACTORY PRESET
C15
ACL-COEFF
N/A 94
FACTORY PRESET
C16
ACL-COEFF
N/A 80
FACTORY PRESET
C17
ACL-WAIT
N/A 2
FACTORY PRESET
C18
ACL-THRESHOLD
N/A 9
FACTORY PRESET
C19
MACROVISION
N/A 3
FACTORY PRESET
C1A
OSD SELECT
N/A 1
FACTORY PRESET
C1B
KILLER ON
N/A 6
FACTORY PRESET
C1C
KILLER OFF
N/A 20
FACTORY PRESET
C1D
KILLER TIME
N/A 3
FACTORY PRESET
C1E
ACC THRESHOLD
N/A 17
FACTORY PRESET
C1F
ACC OFF
N/A 7
FACTORY PRESET
C20
MUTE TIME
N/A 11
FACTORY PRESET
MTS Adjustments
M0
INPUT LEVEL
0 ~ 63 33
M1
HIGH-LEVEL
SEPARATION
0 ~ 63 25
M2
LOW-LEVEL
SEPARATION
0 ~ 15 6
M3
AGC ADJ
N/A 0
FACTORY PRESET
Options Adjustments
S0
SHARPNESS PW
N/A 3
FACTORY PRESET
S1
SHARPNESS OW
N/A 3
FACTORY PRESET
S2
HALFTONE
N/A 0
FACTORY PRESET
S3
TVC DELAY
N/A 0
FACTORY PRESET
S4
TVY DELAY
N/A 0
FACTORY PRESET
S5
GAMMA
N/A 13
FACTORY PRESET
S6
VIDEO Y DELAY
N/A 0
FACTORY PRESET
S7
VIDEO C DELAY
N/A 0
FACTORY PRESET
S8
COMB BPF
N/A 0
FACTORY PRESET
S9
COMB 2D
N/A 1
FACTORY PRESET
SA
COLOR KILLER
LEVEL
N/A 0
FACTORY PRESET
