SERVICE MODE, CONT. (ELECTRONIC CONTROL)
SERVICE ADJUSTMENT VALUES
Model _____________________________________________ Ser #_____________ Date_________________
Note: Record the original settings PRIOR to modifying the registers.
Mode
Service
Adjustment
Adjustment
Range
Def.
Val.
Original
Value
New
Value
Options Adjustments (Cont.)
SB
KILLER
THRESHOLD
N/A 0
FACTORY PRESET
SC
ACC SW
N/A 0
FACTORY PRESET
SD
ACC AMP OFF1
N/A 100
FACTORY PRESET
SE
ACC AMP OFF2
N/A 0
FACTORY PRESET
SF
ACC AMP ON
N/A 20
FACTORY PRESET
S10
ACC AMP CTL
N/A 3
FACTORY PRESET
S11
BGP POSITION
N/A 21
FACTORY PRESET
S12
OSD R
N/A 30
FACTORY PRESET
S13
OSD G
N/A 30
FACTORY PRESET
S14
OSD B
N/A 30
FACTORY PRESET
S15
NOISE KILLER
TIME
N/A 5
FACTORY PRESET
S16
NOISE KILLER
(ACC)
N/A 50
FACTORY PRESET
S17
HV TIMING
N/A 2
FACTORY PRESET
VCJ Adjustments (Black Expansion)
P0
FORCE BS
N/A 1
FACTORY PRESET
P1
DET ON/OFF
N/A 1
FACTORY PRESET
P2
ROM SEL
N/A 3
FACTORY PRESET
P3
ROM CURVE
N/A 2
FACTORY PRESET
P4
BS ON/OFF
N/A 1
FACTORY PRESET
P5
BS TIME
CONSTNAT
N/A 5
FACTORY PRESET
P6
THRESHOLD V
N/A 4
FACTORY PRESET
P7
THRESHOLD F1
N/A 129
FACTORY PRESET
P8
THRESHOLD F1
N/A 1
FACTORY PRESET
P9
THRESHOLD
OFF1
(EFFECT OFF)
N/A 35
FACTORY PRESET
PA
THRESHOLD F2
N/A 99
FACTORY PRESET
PB
THRESHOLD F2
N/A 1
FACTORY PRESET
PC
THRESHOLD
OFF2
(EFFECT OFF)
N/A 30
FACTORY PRESET
Mode
Service
Adjustment
Adjustment
Range
Def.
Val.
Original
Value
New
Value
VCJ Adjustments, Cont. (Black Expansion)
PD
THRESHOLD F3
N/A 80
FACTORY PRESET
PE
THRESHOLD F3
N/A 1
FACTORY PRESET
PF
THRESHOLD
OFF3
(EFFECT OFF)
N/A 21
FACTORY PRESET
P10
THRESHOLD
ON1
N/A 37
FACTORY PRESET
P11
THRESHOLD
ON2
N/A 33
FACTORY PRESET
P12
THRESHOLD
ON3
N/A 25
FACTORY PRESET
P13
CURVE1
N/A 3
FACTORY PRESET
P14
CURVE2
N/A 3
FACTORY PRESET
P15
CURVE3
N/A 3
FACTORY PRESET
P16
RATIO1
N/A 0
FACTORY PRESET
P17
RATIO2
N/A 2
FACTORY PRESET
P18
RATIO3
N/A 3
FACTORY PRESET
Other Adjustments
X0
AFCT
0~127 60
X1
AFCB
0 ~ 127 29
X2
AFCC
0 ~ 127 42
X3
CLOCK
0 ~ 255 128
Note: Some adjustments modes may not be
available on all models, depending on
applicability.
Printed in USA
K01042221ZR0412
