REPLACEMENT PARTS LIST
Models: CT-32G6E/CE/UE
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
- 33 -
094-01
PARTS LIST
Parts List
R561 ERG2FJ102H RES,M 1K-J-2W
R562 ERG3FJ680H RES,M 68-J-3W
R563 ERG1SJ150P RES,M 15-J-1W
R572 ERJ6GEYJ132V RES,M 1.3K-J-1/10W
R605 ERDS2TJ103T RES,C 10K-J-1/4W
R606 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R607 ERJ6GEYJ102V RES,M 1K-J-1/10W
R608 ERJ6GEYJ104V RES,M 100K-J-1/10W
R752 ERDS2TJ333T RES,C 33K-J-1/4W
R753 ERDS2TJ103T RES,C 10K-J-1/4W
R754 ERG3FJ562 RES,M 5.6K-J-3W
R755 ERDS2TJ563T RES,C 56K-J-1/4W
R756 ERDS2TJ103T RES,C 10K-J-1/4W
R757 ERDS2TJ224T RES,C 220K-J-1/4W
R758 ERDS2TJ273T RES,C 27K-J-1/4W
R759 ERDS2TJ222T RES,C 2.2K-J-1/4W
R760 EVND8AA03B53 CONTROL 5K
R761 EVND8AA03B14 CONTROL 10K
R762 ERDS2TJ182T RES,C 1.8K-J-1/4W
R763 ERDS2TJ183T RES,C 18K-J-1/4W
R764 ERDS2TJ154T RES,C 150K-J-1/4W
R765 ERDS2TJ272T RES,C 2.7K-J-1/4W
R766 ERDS2TJ362T RES,C 3.6K-J-1/4W
R767 ERDS2TJ272T RES,C 2.7K-J-1/4W
R768 ERQ2CJP100S RES,F 10-J-2W
R801 ERF7ZK1R5 RES,W 1.5-K-7W
R802 ERDS2TJ684T RES,C 680K-J-1/4W
R803 ERG2FJ100H RES,M 10K-J-1/2W
R804 ERG2FJ104H RES,M 100K-J-2W
R805 ERX2FZJR18H RES,M .18-J-2W
R806 ERX2FJR56H RES,M .56-J-2W
R807 ERDS2TJ681T RES,C 680-J-1/4W
R808 ERDS2TJ4R7T RES,C 4.7-J-1/4W
R809 ERDS2TJ472T RES,C 4.7K-J-1/4
R815 ERC12ZGM825D RES,S 8.2MEG-M-1/2
R821 ERDS1FJ1R0T RES,C 1.0-J-1/2W
R822 ERDS1FJ1R0T RES,C 1.0-J-1/2W
R823 ERDS1FJ272T RES,C 2.7K-J-1/2W
R824 ERDS2TJ223T RES,C 22K-J-1/4W
R825 ERDS2TJ272T RES,C 2.7K-J-1/4W
R828 ERJ6GEYJ104V RES,M 100K-J-1/10W
R830 ERDS2TJ104T RES,C 100K-J-1/4W
R831 ERDS2TJ682T RES,C 6.8K-J-1/4W
R850 ERQ12HJR56P RES,F .56-J-1/2W
R2201 ERJ6GEYJ224V RES,M 220K-J-1/10W
R2203 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2204 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2205 ERJ6GEYJ101V RES,M 100-J-1/10W
R2206 ERJ6GEYJ273V RES,M 27K-J-1/10W
R2301 ERQ2CJP3R9S RES,F 3.9-J-2W
R2307 ERJ6GEYJ103V RES,M 10K-J-1/10W
REF NO. PART NO. DESCRIPTION
R2350 ERDS2TJ391T RES,C 390-J-1/4W
R2351 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R2352 ERJ6GEYJ683V RES,M 68K-J-1/10W
R2353 ERJ6GEYJ124V RES,M 120K-J-1/10W
R2354 ERJ6GEYJ123V RES,M 12K-J-1/10W
R2355 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R2356 ERJ6GEYJ101V RES,M 100-J-1/10W
R2357 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R2365 ERDS2TJ102T RES,C 1K-J-1/4W
R2370 ERJ6GEYJ103V RES,M 10K-J-1/10W
R3001 ERDS2TJ101T RES,C 100-J-1/4W
R3005 ERJ6GEYJ334V RES,M 330K-J-1/10W
R3007 ERDS2TJ151T RES,C 150-J-1/4W
R3008 ERJ6GEYJ151V RES,M 150-J-1/10W
R3009 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3010 ERJ6GEYJ334V RES,M 330K-J-1/10W
R3011 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3013 ERJ6ENF75R0V RES,M 75.0-F-1/10W
R3014 ERJ6ENF75R0V RES,M 75.0-F-1/10W
R3050 ERJ6GEYJ101V RES,M 100-J-1/10W
R3051 ERJ6GEYJ101V RES,M 100-J-1/10W
SWITCHES
S001 EVQPF106K SWITCH
S002 EVQPF106K SWITCH
S003 EVQPF106K SWITCH
S004 EVQPF106K SWITCH
S005 EVQPF106K SWITCH
S008 EVQPF106K SWITCH
S009 EVQPF106K SWITCH
TRANSFORMERS
T501 TLH15452
TRANSFORMER, HORIZONTAL
DRIVER
T551 KFT5AA370F TRANSFORMER, FLYBACK
T801 ETS35AA5E3NC TRANSFORMER
CRYSTALS/FILTERS
X001 TSSA092 CRYSTAL OSCILLATOR
X002 AF080005BE CRYSTAL OSCILLATOR
OTHERS
TNR001 ENG36604G TUNER
M001 EUR501450 REMOTE CONTROL
M002 UR50EC1190A BATTERY COVER, REMOTE CONTROL
M003 TSX2AA0111 AC LINE CORD
M004 TMW2A97121 STRAIN RELIEF: AC LINE CORD
M005 M80JUA061X CRT 32”
M006 TJSC00300 CRT SOCKET
DY TLY2AA008 YOKE, DEFLECTION
M007 JH291U-009 YOKE, CONVERGENCE
DEG TSP2AA007 COIL, DEGAUSSING 32”
M008 TXF3A01AFRA ASSY, DAG GND
M009 TMM2A30702 WEDGE, YOKE
M010 0FMK014ZZ CONVERGENCE CORRECTOR STRIP
REF NO. PART NO. DESCRIPTION
