 Piping Length Characteristic Cooling
[Condition] Room temperature: 81°F (DBT), 66°F (WBT)
Operation condition: High fan speed
Outdoor temperature: 95°F (DBT)
Compressor Freq: Fc
A) Indoor unit capacity: Cooling (2.8: CS-E9NKUAW), service mode frequency = 28Hz
2.500
2.600
2.700
2.800
2.900
3.000
9 141924293439444954596469747984
Piping Length (ft)
Cooling
Capacity (kW)
136.500
137.500
138.500
139.500
140.500
141.500
9 141924293439444954596469747984
Piping Length (f t)
Gas Side Piping
Pressure (PSI)
57.500
58.000
58.500
59.000
59.500
9 141924293439444954596469747984
Piping Length (ft)
Outlet Air
Temperature (°F
)
208 230
3.400
3.500
3.600
3.700
3.800
3.900
4.000
9 141924293439444954596469747984
Piping Length (ft)
Current
(A)
