Panasonic CU-2E18NBU - Page 38

38
 Piping Length Characteristic Cooling
[Condition] Room temperature: 81°F (DBT), 66°F (WBT)
Operation condition: High fan speed
Outdoor temperature: 95°F (DBT)
Compressor Freq: Fc
B) Indoor unit capacity: Cooling (3.2: CS-E12NKUAW), service mode frequency = 33Hz
2.600
2.700
2.800
2.900
3.000
3.100
3.200
3.300
3.400
9 141924293439444954596469747984
Piping Length (ft)
Cooling
Capacity (kW)
126.000
127.000
128.000
129.000
130.000
131.000
132.000
133.000
134.000
135.000
136.000
137.000
138.000
139.000
140.000
9 141924293439444954596469747984
Piping Length (f t)
Gas Side Piping
Pressure (PSI)
55.500
56.000
56.500
57.000
57.500
58.000
58.500
9 141924293439444954596469747984
Piping Length (ft)
Outlet Air
Temperature (°F
)
208 230
4.000
4.100
4.200
4.300
4.400
4.500
4.600
4.700
9 141924293439444954596469747984
Piping Length (ft)
Current
(A)
