3. Specifications
3.1 CU-2TZ41TBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 1.6kW + 2.5kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
Cooling Operation
Capacity
kW 4.1 (1.5 ~ 4.7)
BTU/h 14000 (5120 ~ 16000)
Electrical
Data
Running Current A 4.60
Power Input kW 0.99 (0.27 ~ 1.38)
EER W/W 4.14 (5.56 ~ 3.41)
Annual Energy Consumption (A.E.C) kWh 495
Annual Consumption kWh 202
Noise
Sound Pressure Level dB-A (H/L) 48 / -
Sound Power Level dB (H/L) 63 / -
Heating Operation
Capacity
kW 4.4 (1.1 ~ 6.3)
BTU/h 15000 (3750 ~ 21500)
Electrical
Data
Running Current A 4.60
Power Input kW 0.99 (0.22 ~ 1.78)
COP W/W 4.44 (5.00 ~ 3.54)
Annual Consumption kWh 1139
Noise
Sound Pressure Level dB-A (H/L) 50 / -
Sound Power Level dB (H/L) 65 / -
Maximum Current A 11.5
Maximum Input Power W 2.60k
Starting Current A 4.60
Dimension
Height mm 542
Width mm 780 (+70)
Depth mm 289
Net Weight kg 35
Pipe Length Range (1 room) m 3 ~ 20
Maximum Pipe Length (Total Room) m 30
Piping
Standard Length m 5
Height Difference m 10
Add. Gas Amount g/m 15
Pipe Length for Add. Gas m 20
Refrigerant Pipe Diameter
Liquid Side mm (inch) 6.35 (1/4)
Gas Side mm (inch) 9.52 (3/8)
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Rated Output W 900
Fan Motor
Type Propeller Fan
Motor Type DC Motor (8-poles)
Rated Output W 40
Fan Speed High (Cooling / Heating) RPM 920 / 890
