15 Replacement Part List (Indoor Unit)
15.1. CS-F18DTE5
NO. PART DESCRIPTION QTY. CS-F18DTE5
1 CABINET TOP PLATE 1 CWE001015
2 CABINET FRONT PLATE 1 CWG07K1009
3 CABINET SIDE PLATE (L) 1 CWD63K1001
4 VANE SUPPORTER (L) 1 CWG071146
5 CATCHER 1 CWH601005
6 CABINET SIDE PLATE (R) 1 CWD63K1002
7 VANE SUPPORTER (R) 1 CWG071147
8 BLOWER WHEEL BASE ASS’Y 1 CWD90K1007
9 BRACKET FAN MOTOR ASS’Y 1 CWD54K1006
10 BEARING 1 CWH64C1001
11 BEARING COVER 1 CWD911196
12 FAN SHAFT 1 CWH631030
13 COUPLING SHAFT COMPLETE 1 CWH08C1001
14 SCREW-COUPLING SHAFT COMPLETE 2 CWH55424
15 AIR GUIDER B. WHEEL (TOP) 4 CWD321026
16 AIR GUIDER B. WHEEL (BOTTOM) 4 CWD321027
17 BLOWER WHEEL 1 CWH011004
18 BLOWER WHEEL 3 CWH011009
19 FAN MOTOR 1 CWA921052
20 FAN MOTOR SUPPORTER 2 CWD93C1027
21 SIDE FILTER SEAL 1 CWD911158
22 SEPARATOR 1 CWD911106
23 EVAPORATOR COMPLETE 1 CWB30C1750
24 TUBE ASS’Y (CAPIL. TUBE-EVA) 1 CWT07K1246
25 FLARE NUT (1/4”) 1 CWT251032
26 FLARE NUT (1/2”) 1 CWT251026
27 HEATPROOF TUBE [LIQUID] 1 CWG021024
28 HEATPROOF TUBE [GAS] 1 CWG021022
29 WATERPROOF COVER 1 CWG251006
30 SENSOR-EVAPORATOR 1 CWA50C2232
31 HOLDER SENSOR 1 CWH32137
32 VANE COMPLETE 1 CWE24C1016
33 VANE SIDE HOLDER 2 CWH511027
34 FULCRUM 2 CWH621008A
35 VERTICAL VANE HOLDER (MANUAL) 3 CWD911107
36 VERTICAL VANE (HORIZ.AIR FLOW) 12 CWE241051
37 CONNECTING BAR 6 CWE261019
38 AIR SWING MOTOR COMPLETE 1 CWA98C1004
39 CONTROL BOARD ASS’Y 1 CWH10K1050
40 TERMINAL BOARD 1 CWA281031
41 CAPACITOR-FAN MOTOR (MF/V) 1 DS451125BPQB
42 ELECTRONIC CONTROLLER-MAIN 1 CWA73C1694
43 LOCKING GUARD SPACER 6 CWH541026
44 CONTROL BOARD COVER-COMPLETE 1 CWH13C1106
45 TRANSFORMER 1 CWA40C1031
46 SENSOR COMPLETE 1 CWA50C2233
48 CABLE CLIP (CORD CLAMPER) 1 CWH88133
49 WIRE SADDLE 4 CWH881016
50 DRAIN PAN ASS’Y 1 CWH40K1014
51 DRAIN PLUG 1 CWB821002
52 CABINET BOTTOM PLATE 1 CWE051001A
53 CURVED WIRE 1 CWH751002
54 RAY RECEIVER HOLDER 1 CWD911428
55 INTAKE GRILLE (LARGE) 2 CWE221029
56 GRILLE SLIDE HOOK 4 CWH891001
57 AIR FILTER (MAIN) 2 CWD001169
58 AIR FILTER (SIDE) 1 CWD001041
