3 Product Specification
3.1. CS-F18DTE5 CU-J18DBE5
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
Indoor Unit Outdoor Unit
ITEM / MODEL Main Body CS-F18DTE5 CU-J18DBE5
Remote CZ-RD513C (Wired)
Control CZ-RL513T (Wireless)
Cooling Capacity kW 5.0
BTU/h 17,100
Refrigerant Charge-less m 20
Standard Air Volume for High Speed
m
3
/min
14 57
cfm 494 2013
Outside Dimension (H × W × D) mm 210 × 1245 × 700 795 × 900 × 320
inch 8-9/32 × 49-1/64 × 27-9/16 31-5/16 × 35-7/16 × 12-19/32
Net Weight kg (lbs) 33 (73) 57 (126)
Piping Refrigerant Gas mm (inch) O.D Ø 12.70 (1/2) Flared Type
Connection Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain O.D Ø 20 I.D Ø 20
Compressor Type, Number of Set — Hermetic, 1
Starting Method — Permanent Split Capacitor
Motor Type — 2-pole 1 phase brushless motor
Rated Output kW — 1.5
Fan Type, Number of Set Sirocco fan-4 Mix flow fan-1
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.022 0.07
Air-heat Exchanger (Row × Stage × FPI) Louver-fin type (2 × 12 × 18) Corrugate-fin type (1 × 36 × 21)
Refrigerant Control — Expansion Valve
Refrigerant Oil (Charged)
cm
3
— FV50S
Refrigerant (Charged) R410A kg (oz) — 1.10 (38.8)
Running Control Switch Wireless or Wired Remote Control —
Adjustment Room Temperature Thermostat —
Noise Level dB (A) Cooling: 41/37 49/-
Power level Cooling: 58/54 65/-
dB
Moisture Removal L/h (Pt/h) 2.8 (5.9)
EER W/W 2.81/2.76/2.72
ITEM / MODEL Condition by ISO5151
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cooling 1.78 1.81 1.84
Running Current A Cooling 8.15 8.10 8.05
Starting Current A 26 27 28
Power Factor % Cooling 99 97 95
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
