Panasonic CU-B14DBE5 - Group Control Equipment

8
2.5. Group Control Equipment
Wired
remote
control
Group control by one remote control
• All air conditioner units are con-
trolled as a whole by remote control.
• All indoor units operate in the same
mode.
[Remote side]
• Optional wired remote con-
trol CZ-RD513C
[Local side]
Not needed
Twin remote control separate control
• Each indoor unit can be operated by
either one of the two remote control.
• Apart from timer setting time, dis-
plays for two remote control are
identical.
• Last button pressed has priority
(main or slave is set at remote con-
trol unit).
[Remote side]
• Optional wired remote con-
trol
[Local side]
• Optional wired remote con-
trol CZ-RD513C
Common
control
Common control / group
• Operation is possible using either
wired or wireless remote control
unit.
• Last button pressed has priority.
• Optional wired remote con-
trol and wireless remote
control
Wired CZ-RD513C
Wireless CZ-RL513T
