Operation Details
Soft Dry Operation Time Diagram
<Description of operation>
a – c, p~r : Cooling Operation
c – p, r – v : Soft Dry Operation
e – f : Soft Dry OFF
j – l : 60 sec. Forced Operation
q – t : Anti Freezing Control
a
b
c
def
g
h
i
j
k
l
m
n
opq
rs
tuv
Basic Time
Compressor
Indoor Fan
Outdoor Fan
Operation LED
1’ 1’
1’6’
6’
6’ 6’
4’
1’
Cooling ON
Cooling OFF
Soft Dry ON
Soft Dry OFF, ON
1.5°C
1.0°C
SLoSLo SLo LoSLo SLo SLo SLoSLo SLo SLo SLo
Indoor
Heat Exchanger
Temp.
10°C
2°C
6’
Intake Air
Temperature
Set Temp.
Operation
Stop
