FAN SPEED, AIR SWING
■ Operation Details
FAN
SPEED
FAN SPEED
• There are 3 fan speeds, as well as
automatic*.
* For automatic fan speed, the
speed of the indoor fan is
automatically adjusted
according to the operation.
• If the operation mode is set to
Fan, the fan speed will be fi xed at
MED/MEDIUM regardless of the
temperature setting.
Air Swing
• If automatic vertical airfl ow direction
has been set, the louvers swing up
and down automatically.
AUTO
AUTO
MANUAL
MANUAL
• There are 4 options for manual
vertical airfl ow direction.
• Keeps the room ventilated.
• Do not adjust the vertical airfl ow
direction louver by hand.
• Horizontal airfl ow direction louver is
manually adjustable.
Troubleshooting
● Air Swing operation 1, 2, 3 are no variance in angle.
►
Only one blowing angle is available for Ceiling model.
● Indoor fan stops occasionally during automatic fan
speed setting.
► This helps to remove the surrounding odours.
● Remote control/display does not work.
► Check the battery insertion and address are correct.
► Signal transmission is out of range.
AIR SWING
AUTO
MANUAL
AIR SWING
MANUAL
AUTO
FAN
SPEED
FAN SPEED
Select fan
speed.
LO/LOW
MED/MEDIU
M
AUTO
HI/HIGH
