Unit CS-E12DKEW CU-E12DKE
Dimensions Height inch (mm) 11 - 1/32 (280) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 7 - 7/32 (183) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 82 (37)
Compressor Type — Hermetic Rotary
Motor Type — Brushless (6-pole)
Rated Output W — 700
Air Circulation Type Cross-flow Fan Propeller Fan
Material ASG20k1 P.P
Motor Type Transistor (8-poles) Induction (6-poles)
Input W — 65.9
Rate Output W 30 29
Fan Speed Lo (Cool/Heat) rpm 910/1,080 —
Me (Cool/Heat) rpm 1,165/1,290 —
Hi (Cool/Heat) rpm 1,420/1,500 830
SHi (Cool/Heat) rpm 1,460/1,540 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2/15 2/24
FPI 21 17
Size (W × H × L) mm 610 × 315 × 25.4 718.4
689.8
× 504 × 36.4
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — RB68A (320)
Refrigerant (R410A) g (oz) — 980 (34.6)
Thermostat Electronic Control —
Protection Device Electronic Control Electronic Control
Length mm — C1, C2 ; 1,120, C3 ; 370
Capillary Tube Flow Rate l/min — C1, C2 ; 4.9, C3 ; 19.6
Inner Diameter mm — C1, C2 ; 1.2, C3 ; 1.7
Air Filter Material
Style
P.P.
Honeycomb
—
Fan Motor Capacitor µF, VAC — 2.0 µF, 440 VAC
Compressor Capacitor µF, VAC — 65 µF, 350 VAC
•
Specifications are subject to change without notice for further improvement.
10
CS-E9DKEW CU-E9DKE / CS-E12DKEW CU-E12DKE
