Panasonic CU-E18DBE

17 Replacement Parts List (Outdoor Unit)
17.1. CU-E15DBE CU-E18DBE CU-E21DBE
REF NO. DESCRIPTION & NAME QTY. CU-E15DBE CU-E18DBE CU-E21DBE REMARKS
1 CHASSY ASSY 1 CWD50K2085
← ←
2 ANTI-VIBRATION BUSHING 3 CWH50077
← ←
3 COMPRESSOR 1 5CS130XAD04
← ←
O
4 NUT-COMPRESSOR MOUNT 3 CWH56000
← ←
5 SOUND PROOF MATERIAL 1 CWG302302
← ←
6 FAN MOTOR BRACKET 1 CWD541084 CWD541054
←
7 FAN MOTOR 1 CWA981166
← ←
O
8 SCREW - FAN MOTOR BRACKET 2 CWH551060
← ←
9 SCREW - FAN MOTOR MOUNT 3 CWH551106
← ←
10 PROPELLER FAN ASSY 1 CWH03K1016
← ←
11 NUT - PROPELLER FAN 1 CWH56053
← ←
12 CONDENSER 1 CWB32C1583 CWB32C1527 CWB32C1526
14 TUBE ASS’Y COMPLETE (CAP TUBE/EXP.VALVE) 1 CWT023679
←
CWT023610 O
15 4 WAYS VALVE 1 CWB001026
← ←
16 STRAINER 1 CWB11094
← ←
18 HOLDER - COUPLING 1 CWH351035
← ←
19 3 WAYS VALVE (GAS) 1 CWB011170
← ←
O
20 2 WAYS VALVE (LIQUID) 1 CWB021292
←
CWB021306 O
22 SOUND PROOF BOARD 1 CWH151050
← ←
23 TERMINAL COVER 1 CWH171001
← ←
24 NUT-TERMINAL COVER 1 CWH7080300
← ←
25 SENSOR COMPLETE (COMP. TOP) 1 CWA50C2185
← ←
26 HOLDER SENSOR 1 CWH321010
← ←
27 V-COIL COMPLETE (4-WAYS VALVE) 1 CWA43C2168
← ←
28 V-COIL COMPLETE (EXPAND VALVE) 1 CWA43C2141
← ←
29 SENSOR COMPLETE (COMP. DISC.) 1 CWA50C2180
← ←
30 SENSOR COMPLETE 1 CWA50C2181
← ←
31 REACTOR 1 CWA421069
← ←
32 CONTROL BOARD CASING (SIDE) 1 CWH102273
← ←
33 TERMINAL BOARD ASSY 1 CWA28K1110
← ←
34 FUSE HOLDERS 1 K3GB1PH00016
← ←
35 FUSE 1 K5D303BBA002
← ←
36 CONTROL BOARD CASING (TOP) 1 CWH102204
← ←
37 CONTROL BOARD CASING (BOTTOM) 1 CWH102282
← ←
38 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1767R CWA73C1768R CWA73C1769R O
40 CONTROL BOARD COVER (TOP) 1 CWH131167
← ←
41 CABINET SIDE PLATE (LEFT) 1 CWE041082A
← ←
42 HANDLE 1 CWE161010
← ←
43 CABINET SIDE PLATE (RIGHT) 1 CWE041083A
← ←
44 HANDLE 2 CWE16000E
← ←
45 CABINET FRONT PLATE CO. 1 CWE06K1043
← ←
46 WIRE NET 1 CWD041041A
← ←
47 CABINET TOP PLATE 1 CWE031031A
← ←
48 CONTROL BOARD COVER (BOTTOM) 1 CWH131168
← ←
49 CONTROL BOARD COVER (TOP) 1 CWH131169A
← ←
50 OPERATING INSTRUCTION 1 CWF564379
← ←
51 OPERATING INSTRUCTION 1 CWF564380
← ←
52 INSTALLATION INSTRUCTION 1 CWF612604
← ←
53 INSTALLATION INSTRUCTION 1 CWF612605
← ←
54 INSTALLATION INSTRUCTION 1 CWF612606
← ←
56 DRAIN HOSE 1 CWH5850080
← ←
57 PACKING 1 CWB81012
← ←
58 SOUND PROOF MATERIAL 1 CWG302290 CWG302270
←
59 SOUND PROOF MATERIAL 1 CWG302301 CWG302300
←
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
