Warning
This sign warns of death or serious injury.
■ Operation Precautions
● Do not share outlet.
● Do not insert plug to operate the unit. Do not
pull out plug to stop the unit.
● Do not operate with wet hands.
● Do not damage or modify the power cord.
● Do not insert finger or other objects into the
indoor or outdoor units.
● Do not expose directly to cold air for a long
period.
● Plug in properly.
● Use specified power cord.
● If abnormal condition (burnt smell, etc.)
occurs, switch off and unplug the power
supply.
Caution
This sign warns of injury.
● Do not pull the cord to disconnect the plug.
● Do not wash the unit with water.
● Do not use for other purposes such as
preservation.
● Do not use any combustible equipment at
airflow direction.
● Do not sit or place anything on the outdoor unit.
● Switch off the power supply before cleaning.
● Ventilate the room regularly.
● Pay attention as to whether the installation
rack is damaged after long period of usage.
● Switch off the power supply if the unit is not
used for a long period.
NAME OF EACH PART
■ Indoor Unit
1
Front Panel
2
Air Intake Vent
3
Power Supply Cord
4
Air Outlet Vent
5
Vertical Airflow Direction Louver
6
Horizontal Airflow Direction Louver
(manually adjusted)
7
Auto Operation Button
(when the front panel is opened)
8
Air Filters
9
Indicator Panel
Auto Operation / Test Run Operation
If the remote control not available, press the
button for Auto Operation. Keeping this button
depressed for more than 5 seconds to start
the Test Run Operation (cooling only), for the
purpose of installation or repairment only.
1
2
3
9
7
6
5
4
8
■ Outdoor Unit
1
Air Intake Vents
2
Ground Terminal
(Inside cover)
3
Piping
4
Connecting Cable
5
Drain Hose
6
Air Outlet Vent
■ Accessories
● Remote Control
● Two dry-cell batteries.
1
2
3
4
5
6
1
2
3
4
5
6
● POWER : Green
(Operation)
● TIMER: Orange
F563553/01-08/EN 5/6/02, 10:34 am3
