Panasonic CU-UV5RKP - Parts List

Part List
No. Part No. Part Name Q’ty Remark
1 CWC80030003 Installation Plate 1
2 CWC10250103A Base 1
3 CWC70020017A Cross Fan 1
4 CWC70100010 Bearing Mount 1
5 CWC1205976 Evaporator 1
6 CWC70251833A Water Drainage Assembly 1
7 CWC70321035A Vertical Vane Assembly 2
8 CWC70251841A Face Frame 1
9 CWC70321022A Screw Cover 2
10 CWC70250106 Air Filter 2
11 CWC0705326A Front Panel 1
12 CWC70120044A Power Supply Cord 1
13 CWC70251837A Vane 1
14 CWC70110011 Drainage Hose 1
15 CWC0705928A Display PCB Cover 1
16 CWC0900944A Display PCB(Digital) 1
17 CWC70040004 Cable Clamp 1
18 CWC0900994A Main PCB(Digital) 1
19 CWC0705987 Electrical Box 1
20 CWC70020011 Vane Motor 1
21 CWC73010501 Sensor Holder 1
22 CWC70030047 Indoor Motor 1
23 CWC70320111 Indoor Motor Cover 1
24 CWC70240023A Transformer 1
25 CWC70230001 Indoor Sensor Assembly 1
26 CWC70320101A In And Out Pipe Fixer 1
27 CWC0901058A Remote Controller 1
28 CWC90060827A Indoor Carton 1
29 CWC91990104 Left Foaming 1
30 CWC91990105 Right Foaming 1
Not shown in
Explosion view
INDOOR UNIT：CS-UV5RKP
Air Conditioner Service Manual
13
