Model
Indoor CS-UV5RKP CS-UV9RKP
Outdoor CU-UV5RKP CU-UV9RKP
Performance Test Condition
Power supply
Phase.Hz 50 50
V 220 220
Cooling
Capacity
KW 1.52 2.49
BTU/h 5200 8500
KJ/h 5512 9010
Running Current A 1.8 3.7
Input Power W 405 830
EER
W/W 3.75 3.00
Btu/h/W 12.80 10.24
Power Factor % 98 99
Indoor Noice(H/L) dB-A 37 40
Outdoor Noice(H/L) dB-A 50 50
Max Current(A)/Max Input Power (W) 2.3/520 4.8/1070
Starting Current(A) 11 20
Compressor
Type Rotary Rotary
Motor Type Single phase induction Single phase induction
Output Power W 395 660
Indoor Fan
Type Cross flow Cross flow
Material ASG30 ASG30
Motor Type PG PG
Input power W 40 27
Output power W 22 15
Speed
Lo rpm 1000 1000
Me rpm 1170 1170
Hi rpm 1270 1270
Outdoor Fan
Type Axial flow Axial flow
Material ASG20 ASG20
Motor Type AC AC
Input Power W 45 45
Output Power W 25 25
Speed HI rpm 895 895
Moisture Removal L/h(Pth) 0.55 0.56
Indoor Airflow
Lo m³/min(π³/min) 5.5 7.5
Me m³/min(π³/min) 6.7 8.5
HI m³/min(π³/min) 8 9.7
Outdoor Airflow HI m³/min(π³/min) 23.5 23.5
SPECIFICATION
Air Conditioner Service Manual
