Part List
No. Part No. Part Name Q’ty Remark
1 CWC71990038 Grille 1
Optional
2 CWC81990014 Top Cover 1
3 CWC1200048 Condenser 1
4 CWC81990018A Outdoor Motor Supporter 1
5 CWC70040062 Outdoor Motor 1
6 CWC70030006A Propeller Fan 1
7 CWC81990011 Left Grille Supporter 1
8 CWC81990016 Front Plate 1
9 CWC70251929 Fan Guard 1
10 CWC1206785 Capillary Assembly 1
11 CWC1205947 Compressor And It Accessories 1 ASM99V1VDZ
12 CWC1205917 Discharge Pipe 1
13 CWC1205918 Suction Pipe 1
14 CWC0800528 Base 1
15 CWC20120025 Two-way Valve 1
16 CWC81990013 Valve Supporter 1
17 CWC20130039 Three-way Valve 1
18 CWC81990012 Right Plate 1
19 CWC73521301A Electrical Box Cover 1
20 CWC80010006 Capacitor Strip 1
21
CWC70040002
Cable Clamp
φ7)
1
22 CWC70500130 Terminal 1
23 CWC70100045B Compressor Capacitor 1
24 CWC70100031A Fan Motor Capacitor 1
25 CWC81990010 Electrical Parts Box 1
26 CWC81990019 Partition plate 1
27 1070060004 Valve cover 1
28 CWC1313638 Base Carton 1
29 CWC1313639HK Cabinet Carton 1
30 CWC1313637 Base Foaming 1
31 CWC1313636 Cover Forming 1
OUTDOOR UNIT：CU-UV5RKP
Not shown in the
Explosion view.
Air Conditioner Service Manual
1４
