Part List
No. Part No. Part Name Q’ty Remark
1 CWC80030008 Installation Plate 1
2 CWC10320107B Base 1
3 CWC70020026A Cross Fan 1
4 CWC70100010 Bearing Mount 1
5 CWC1205979 Evaporator 1
6 CWC70321032A Water Drainage Assembly 1
7 CWC70321035A Vertical Vane Assembly 2
8 CWC70321030A Face Frame 1
9 CWC70321022A Screw Cover 2
10 CWC70320109 Air Filter 2
11
CWC0705327B Front Panel 1
12 CWC70120044A Power Supply Cord 1
13 CWC70321034A Vane 1
14 CWC70110011 Drainage Hose 1
15 CWC0705928A Display PCB Cover 1
16 CWC0900944A Display PCB(Digital) 1
17
CWC70040004
Cable Clamp
1
INDOOR UNIT：CS-UV9RKP
17
CWC70040004
Cable
Clamp
1
18 CWC0900994A Main PCB(Digital) 1
19 CWC0705987 Electrical Box 1
20 CWC70020011 Vane Motor 1
21 CWC73010501 Sensor Holder 1
22 CWC70030047 Indoor Motor 1
23 CWC70320111 Indoor Motor Cover 1
24 CWC70240023A Transformer 1
25 CWC70230001 Indoor Sensor Assembly 1
26 CWC70320101A In And Out Pipe Fixer 1
27 CWC0901058A Remote Controller 1
28 CWC90060828B Indoor Carton 1
29 CWC91990102 Left Foaming 1
30 CWC91990103 Right Foaming 1
Not shown in
Explosion view
