Panasonic CU-UV5RKP User Manual

Model
Indoor CS-UV5RKP CS-UV9RKP
Outdoor CU-UV5RKP CU-UV9RKP
Refrigeration
Cycle
Control Device
Rotary Rotary
Refrigerant Oil cm³ 180 350
Refrigerant Type g(oz) R410A R410A
Dimension
Height(I/D / O/D) mm(Inch) 718/600 770/600
Width(I/D / O/D) mm(Inch) 240/232 240/232
Depth(I/D / O/D) mm(Inch) 180/500 180/500
Weight Net(I/D / O/D) kg
（
Ib
）
6.7/19.7 6.9/24.0
Paping
Pipe Diameter(Liquid / Gas) mm(Inch) 6.35/9.52 6.35/9.52
Standard length m(π) 5 5
Length range(min-max) m(π) (3-15) (3-15)
I/D & O/D Height different m(π) 5 5
Additional Gas Amount g/m(oz/) 20 20
Length for Additional Gas m(π) 12 12
Drain Hose
Inner Diameter mm 15 15
Lenghth mm 600 600
Indoor Heat
Exchanger
Fin Material Hydrophilic aluminium Hydrophilic aluminium
Fin Type window window
Row x Stage x FPI 2x 362 x16.9 2x 403 x16.9
Size(W x H x L) mm 25.4x231x544 25.4x231x604
Outdoor Heat
Exchanger
Fin Material Hydrophilic aluminium Hydrophilic aluminium
Fin Type window window
Row x Stage x FPI 1x 451 x19.5 1x 385 x16.9
Size(W x H x L) mm 588x449x11.6 602x462x18.2
Air filter
Meterial PP+ABS PP+ABS
Type Anti-dust Anti-dust
Power Supply 220V 220V
Power Supply cord A 15 15
Themostat Sensor Sensor
Protection Device OLP OLP
Indoor operation Range
Maximum
℃
Dry bulb 32 32
Wet bulb 23 23
Minimum
℃
Dry bulb 21 21
Wet bulb 15 15
Outdoor operation Range
Maximum
℃
Dry bulb 43 43
Wet bulb 26 26
Minimum
℃
Dry bulb 21 21
Wet bulb 15 15
Air Conditioner Service Manual
3

Panasonic CU-UV5RKP Specifications
