Panasonic CZ-RTC5 Installation Instructions

5
(EN)
 Part Names ....................................... 2
 Safety Precautions ........................... 4
 Supplied accessories ...................... 5
 Specifi cations ................................... 5
 Installation Precautions................... 6
 Mounting ........................................... 8
Exposed type ................................ 8
Embedded type ............................ 9
 Setting ............................................. 10
Language ................................... 10
Clock .......................................... 10
Controller name .......................... 10
Service contact ............................11
RC. setting mode ........................ 12
Detailed settings ......................... 12
Auto address .............................. 13
Set elec. consumption ................ 13
 Confi rming Information ................. 14
 Test Operation ................................ 15
Supplied accessories
Screw
M3.8 x 16
(2)
Operating
Instructions
(1)
Quick
Reference
(1)
Clamper
(1)
*Remote control wiring is not supplied. (fi eld supplied item)
CONTENTS
Model No. CZ-RTC5
Dimensions (H) 120 mm x (W) 120 mm x (D) 16 mm
Weight 180 g
Temperature/
Humidity range
0 ˚C to 40 ˚C / 20 % to 80 % (no condensation)
*Indoor use only.
Power Source DC16 V (supplied with indoor unit)
Clock
Precision
± 30 seconds/month (at normal temperature 25 ˚C)
*Adjust periodically.
Holding
time
72 hours (when fully charged)
*Approx. 8 hours are required for full charge.
Number of
connected indoor
units
Up to 8 units
Specifi cations
ENGLISH
業務用リモコンCZ-RTC5据付書En.indd5業務用リモコンCZ-RTC5据付書En.indd5 2015/07/2816:03:222015/07/2816:03:22

Panasonic CZ-RTC5 Specifications

General

Brand	Panasonic
Model	CZ-RTC5
Category	Remote Control
Language	English
