- 17 -
(2)
If abnormalities as mentioned below are found during use, please do not use the Unit and contact your authorized dealer immediately.
• Water leakage.
• No Water Flow.
• Water temperature cannot be controlled.
• ELB lamp does not light up.
(3) Special skill is required for repairing. Never try to repair the Unit by yourself.
(1) Check the following points before asking for repair.
Symptom Points to be checked
Water is not drawn
normally.
No hot water comes out
from the outlet
(no electric supply to the
Unit)
No water flows out from
the Shower Head at all.
Water not hot enough.
1. Check the Filter Unit. Clean the Filter if it is clogged by stain and dirt (refer to Filter Unit Cleaning
at page 16).
2.
Check the Shower Head. Clean the Shower Head if it is clogged by dirt (refer to Shower Head
Cleaning at page 16).
1. Make sure the Main Switch Knob is at “On” position.
2. Make sure the ELB Reset Lever is not slide down.
Push up the ELB Reset Lever to reset the ELB (
refer to
TEST OPERATION at page 21).
3. Make sure to switch on the ON/OFF DP (double pole) Switch.
4. Make sure to switch on the Miniature Circuit Breaker (MCB)
1. Check the Water Volume Knob. Turn the Water Volume Knob clockwise if it is closed.
2.
Check the Main Water Valve. Turn
“On”
the Main Water Valve if it is closed (refer to HOW TO
USE at page 15).
1. Check the WATER FLOW RATE ADJUSTMENT as in page 15.
4. TROUBLESHOOTING
5. SPECIFICATIONS
240 V a.c. 50 Hz
3600 W
Inlet Water Temp. (Off), 1000 W ~ 3600 W
380 kPa / 3.87 kgf/cm² / 55 psi
380(H) mm x 190(W) mm x 93(D) mm
Single Point System (Open Outlet)
DH-3RL1
9.8 kPa / 0.1 kgf/cm² / 1.42 psi
1.6 kg
DH-3RP1
4.9 kPa / 0.05 kgf/cm² / 0.71 psi
2.7 kg
Model No.
Voltage
Power Consumption
Electric Power Control
Min. Water Pressure
Max. Water Pressure
Dimension
Weight
Outlet System
ENGLISH
OPERATION
