Panasonic Diga DMR-EH50 User Manual

15
RQT8023
Getting started
∫ Connection to a stereo amplifier ∫ To enjoy multi-channel surround sound on
DVD-Video
Use one of the following connections to suit the antenna lead.
≥If your television has both lead and coaxial VHF terminals, use
the lead connection to minimize signal loss.
∫ A single twin lead
∫ A twin lead and a coaxial cable
∫ Two twin leads
Use one of the following connections to suit the antenna terminals
on your television. Refer to the television’s operating instructions.
∫ A twin lead and coaxial plug terminal
∫ A twin lead terminal
∫ Two twin lead terminals
∫ Multiple antenna terminals
≥Connect to one of the ANT terminals, then change the television’s
settings as necessary.
Connecting an amplifier or system component
If the antenna connector doesn’t match
S VIDEO
VIDEO
OUT2
OUT2
OUT1
OUT1
Y
P
B
PR
COMPONENT
COMPONENT
VIDEO
VIDEO
OUT
OUT
(
48
48
0p/
p/
48
48
0i
0i
)
AC IN
S VIDEO
VIDEO
IN3
IN3
IN1
IN1
VH
VH
F /UHF
UHF
G - LINK
LINK
RF
RF
IN
IN
RF
RF
OUT
OUT
VIDEO
VIDEO
VIDEO
VIDEO
R-AUDIO-L
R-AUDIO-L
R-AUDIO-L
R-AUDIO-L
DIGITAL AUDIO OUT
DIGITAL AUDIO OUT
(PCM/BITSTREAM)
(PCM/BITSTREAM)
OPTICAL
OPTICAL
OPTICAL IN
AUDIO IN
R L
Optical digital audio cable
Do not bend sharply when
connecting.
Insert fully, with this
side facing up.
Audio cable
This unit
Red White
Red White
Connect an amplifier with a built-in decoder
displaying these logo marks using an optical digital
audio cable and change the settings in “Digital Audio
Output” (
➡ 56).
≥You cannot use DTS Digital Surround decoders not
suited to DVD.
≥Output is not digital with DVD-Audio; however, you can enjoy it in
analog (
➡ left).
[For digital playback, set “Play DVD-Audio in Video Mode” (
➡ 55)
to “Video Mode (Video On)” when the DVD-Audio contains DVD-
Video.]
Amplifier’s rear panel
Amplifier’s rear panel
To OUT 1 or OUT 2
or
Other antenna connections to the unit
300–75 ≠ transformer
from the antenna
(Flat) Twin lead
300 ≠ cable
To this unit’s RF IN
terminal
from the antenna
(Flat) Twin lead 300 ≠ cable
To this unit’s RF IN
terminal(Round)
75 ≠ coaxial cable
VHF/UHF band mixer
from the antenna
To this unit’s RF
IN terminal
300–75 ≠ transformer
(Flat) Twin lead
300 ≠ cable
VHF/UHF band mixer
Other antenna connections to the television
VHF/UHF band separator
Televi si on
75 ≠ coaxial cable
VHF
UHF
75 ≠ coaxial cable
75–300 ≠ transformer
Television
VHF or
UHF
75 ≠ coaxial cable
VHF/UHF band separator
Television
VHF
UHF
ANT 2
ANT 1
Split out
Te lev i sio n
75 ≠ coaxial cable
EH50English.book Page 15 Tuesday, February 1, 2005 6:36 PM
