54
VQT2J83
Specifications
]
Power supply: DC 12 V (DC IN terminal)/
DC 7.2 V (Exclusive battery terminal)
Power consumption (using supplied AC adaptor):
Play Mode: Approx. 22W (Unit only Approx. 18 W)
Recharge mode (Quick Start “Off”): Approx. 17 W
Recharge mode (Quick Start “On”): Approx. 21 W
Standby mode (Quick Start “Off”):
Approx. 0.5 W
Standby mode (Quick Start “On”): Approx. 5 W
AC adaptor:
Power source: AC 100 to 240 V, 50/60 Hz
Power consumption: 42 W
DC output: 12 V, 2500 mA
Battery pack (lithium ion):
Supplied/Optional: DY-DB30
Voltage: 7.2 V
Capacity (Minimum): 5400 mAh
Optional: DY-DB15
Voltage: 7.2 V
Capacity (Minimum): 4200 mAh
Optional: DY-DB100
Voltage: 7.2 V
Capacity (Minimum): 8100 mAh
Dimensions (WkDkH)
(excluding protrusions and battery):
262 mm (W)k55.1 mm (D)k200.5 mm (H)
Mass:
Including
battery
Approx. 1766 g
Without battery Approx. 1531 g
Operating temperature range: i5 to i35 oC
Operating humidity range: 10 to 80 % RH (no condensation)
LCD screen:
10.1q WIDE-SVGA LCD (1024k600kRGB)
HDMI AUDIO/VIDEO output:
Number of terminals: 1 system (19 pins Type A)
LAN:
Number of terminals: 1 system (10BASE-T/100BASE-TX)
USB slot:
Number of terminals: 1 system (USB2.0)
SD card slot:
Number of terminals: 1 system
Speaker:
Output: 0.5 W i 0.5 W (8
≠
)
Headphone output:
Output: ‡ 3.5 mm stereo mini jack
Number of terminals: 1 system
Pickup:
Wave length:
405 nm/660 nm/780 nm (BD/DVD/CD)
Laser power:
CLASS 1M/CLASS 1M/CLASS 1M (BD/DVD/CD)
Wireless LAN Adaptor
Dimensions (WkHkD)
44 mm (W)k27 mm (H)k72 mm (D)
Mass: Approx. 29
g
Antenna: Tx 1, Rx 2
Interface: USB2.0
Standard Compliance:
IEEE802.11n / IEEE802.11a / IEEE802.11g / IEEE802.11b
Transmission system:
MISO-OFDM system, OFDM system, DSSS system
Frequency Range:
IEEE802.11n / IEEE802.11a:
5.15 GHz - 5.35 GHz
5.47 GHz - 5.725 GHz
5.725 GHz - 5.825 GHz (Australia, New Zealand)
IEEE802.11g / IEEE802.11b / IEEE802.11n:
2.4 GHz - 2.4835 GHz
Transfer rate (standard)
*11
:
IEEE802.11n: Tx Max. 150 Mbps, Rx Max. 300 Mbps
IEEE802.11g / IEEE802.11a: Max. 54 Mbps
IEEE802.11b: Max. 11 Mbps
Access Mode:
Infrastructure mode
Security:
WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit / 128 bit)
(This unit supports WPA and WPA2 encryption.)
