Panasonic DMR-EH69

76
RQT9274
Specifications
Recording system DVD-RAM : DVD Video Recording format
DVD-R : DVD-Video format
DVD-R DL (Dual Layer) : DVD-Video format
DVD-RW : DVD-Video format
+R
+R DL (Double Layer)
+RW
Recordable discs
DVD-RAM: 2X SPEED (Ver. 2.0),
2-3X SPEED (Ver. 2.1), 2-5X SPEED (Ver. 2.2)
DVD-R: 1X SPEED (Ver. 2.0), 1-4X SPEED (Ver. 2.0),
1-8X SPEED (Ver. 2.0), 1-16X SPEED (Ver. 2.1)
DVD-R DL (Dual Layer) :
2-4X SPEED (Ver. 3.0), 2-8X SPEED (Ver. 3.0)
DVD-RW: 1X SPEED (Ver. 1.1), 1-2X SPEED (Ver. 1.1),
2-4X SPEED (Ver. 1.2), 2-6X SPEED (Ver. 1.2)
+R: 2.4X SPEED (Ver. 1.0), 2.4-4X SPEED (Ver. 1.1),
2.4-8X SPEED (Ver. 1.2), 2.4-16X SPEED (Ver. 1.3)
+R DL: 2.4X SPEED (Ver. 1.0), 2.4-8X SPEED (Ver. 1.1)
+RW: 2.4X SPEED (Ver. 1.1), 2.4-4X SPEED (Ver. 1.2)
Recording time Maximum 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour, SP: Approx. 2 hours
LP: Approx. 4 hours, EP: Approx. 6 hours/8 hours
[EH69]
Maximum Approx. 567 hours with 320 GB HDD (EP 8 hours mode)
XP: Approx. 71 hours, SP: Approx. 142 hours
LP: Approx. 284 hours, EP: Approx. 426 hours/567 hours
[EH59]
Maximum Approx. 441 hours with 250 GB HDD (EP 8 hours mode)
XP: Approx. 55 hours, SP: Approx. 110 hours
LP: Approx. 221 hours, EP: Approx. 331 hours/441 hours
Playable discs
DVD-RAM : DVD Video Recording format
DVD-R : DVD-Video format, MP3
§1
, WMA
§1
, JPEG
§1
, DivX
§1
DVD-R DL (Dual Layer) : DVD-Video format, MP3
§1
, WMA
§1
,
JPEG
§1
, DivX
§1
DVD-RW : DVD-Video format, DVD Video Recording format
+R, +R DL (Double Layer), +RW
DVD-Video, CD-Audio (CD-DA), Video CD,
CD-R/CD-RW : CD-DA
§ 1
, Video CD
§ 1
, MP3
§ 1
, WMA
§1
,
JPEG
§ 1
, DivX
§ 1
Internal HDD capacity [EH69] 320 GB
[EH59] 250 GB
Optical pick-up System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER specification
Class 1 LASER Product (Pickup)
Wave length:
Laser power:
No hazardous radiation is emitted with the safety protection
Audio
Recording system: Dolby Digital 2ch, Linear PCM (XP mode)
Audio in: AV1/AV2 (21 pin), AV3/AV4 (pin jack)
Input level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Input impedance: More than 10 k≠
Audio out: AV1/AV2 (21 pin), Audio Out (pin jack)
Output level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Output impedance: Less than 1 k≠
Digital audio out: Optical terminal (PCM, Dolby Digital, DTS, MPEG)
HDMI Output 19 pin type A: 1 pc
HDMI
TM
(V.1.3a with Deep Colour)
≥This unit supports “HDAVI Control 4” function.
Video
Video system:
[For]Asia]and]Middle]East]
SECAM (only input)/PAL colour signal, 625 lines, 50 fields
NTSC colour signal, 525 lines, 60 fields
[For]New[Zealand]
PAL co lour signal, 625 lines, 50 fields
NTSC colour signal, 525 lines, 60 fields
Recording system: MPEG2 (Hybrid VBR)
[For]Asia]and]Middle]East] Video in (SECAM/PAL/NTSC):
AV1/AV2 (21 pin), AV3/AV4 (pin jack) 1 Vp-p 75 ≠, termination
[For]New[Zealand] Video in (PAL/NTSC):
AV1/AV2 (21 pin), AV3/AV4 (pin jack) 1 Vp-p 75 ≠, termination
[For]Asia]and]Middle]East] S-Video in (SECAM/PAL/NTSC):
AV2 (21 pin), AV3/AV4 (S terminal) 1 Vp-p 75 ≠, termination
[For]New[Zealand] S-Video in (PAL/NTSC):
AV2 (21 pin), AV3/AV4 (S terminal) 1 Vp-p 75 ≠, termination
Video out (PAL/NTSC):
AV1/AV2 (21 pin), Video Out (pin jack) 1 Vp-p 75 ≠, termination
S-Video out (PAL/NTSC):
AV1 (21 pin), S-Video Out (S terminal) 1 Vp-p 75 ≠, termination
RGB out (PAL/NTSC):
AV1 (21 pin) 0.7 Vp-p (PAL) 75 ≠, termination
Component video output (NTSC 480p/480i, PAL 576p/576i)
Y: 1.0 Vp-p 75 ≠, termination
P
B: 0.7 Vp-p 75 ≠, termination
P
R: 0.7 Vp-p 75 ≠, termination
Television system
[For]Asia]
RF converter output: Not provided
[For]New[Zealand]
RF converter output: Not provided
[For]Middle]East]
RF converter output: Not provided
CD 780 nm wave length
DVD 662 nm wave length
Tuner system Channel coverage
PAL-D,K,
SECAM-D,K,K1
OIRT
VHF:
UHF:
CATV:
R1 to R12
21 to 69
44 MHz to 470 MHz
PAL-B,G,H,
SECAM-B,G
CCIR
VHF:
UHF:
CATV:
E2 to E12
E21 to E69
S01 to S05,
M1 to M10, U1 to U10, S21 to S41
PAL-I
Hong Kong
UHF: 21 to 69
PAL-D
China
VHF:
UHF:
CATV:
1 to 12
13 to 57
Z1 to Z35
Tuner system Channel coverage
PAL-B,G
New Zealand
VHF:
UHF:
CATV:
1 to 11
21 to 69
44 MHz to 470 MHz
Tuner system Channel coverage
PAL-D,K,
SECAM-D,K,K1
OIRT
VHF:
UHF:
CATV:
R1 to R12
21 to 69
44 MHz to 470 MHz
PAL-B,G,H,
SECAM-B,G
CCIR
VHF:
UHF:
CATV:
E2 to E12
E21 to E69
S01 to S05, M1 to M10,
U1 to U10, S21 to S41
PAL-I
South Africa
VHF:
UHF:
4 to 13
21 to 69
