Push the button. LED lights. Use time
knead K knead + swedish
compression L compression + hawaiian
swedish M massage motor
regional roll N up/down motor
tap tap tapping motor
leg massage leg massage leg air massage
reclining up O reclining lift motor
ottoman up P ottoman lift motor
*When replacing the Main Circuit PCB, the use time is counted to zero because the use time is
memorized in Main Circuit PCB.
*When pushing on/off button, the operation returns to normal mode.
7. DISASSEMBLY AND ASSEMBLY INSTRUCTION
(COSMETIC PART AND CHAIR CONSTRUCTION)
7.1. Removing the Head rest, Back rest cushion, Arm rest
1. Unzip the zippers and remove the Back cushion with pillow.
2. Remove four Push-turn rivets on each sides and remove the Side
covers.
11
To Next Page
