Cleaning with the brush
Remove the outer foil section and the inner blades.
(See this page.)
►Cleaning with the long brush
Clean the outer foil section [
A
8],
system outer foil [
A
2], the shaver
body [
A
] and the trimmer [
A
] using
the long brush.
►Cleaning with the short brush
•Cleantheinnerblades[
A
9] using
the short brush by moving it in
direction as illustrated.
•Donotmovetheshortbrush
perpendicularly against the blades as
it will damage the inner blades and
affect their sharpness.
Replacing the system outer foil and
the inner blades
System outer foil Once every year
Inner blades Once every two years
►Removing the outer foil section
Press the foil frame release buttons [
A
7] and
lift the outer foil section [
A
8] upwards.
►Attaching the outer foil section
After turning the foil frame mark ( ) to the
front, securely attach the outer foil section
[
A
8] to the shaver until it clicks.
►Replacing the system outer foil
1. Press the system outer foil release buttons
[
A
] and pull down the system outer foil
[
A
2].
•Donotpressthesystemouterfoilrelease
buttons with excessive force.
Doing so may bend the system outer foil,
preventing complete attachment to the foil
frame.
2. Align the foil frame mark ( ) and the
system outer foil mark ( ) and securely
attach together until it clicks.
►Replacing the inner blades
1. Remove the inner blades [
A
9] one at a time.
2. Insert the inner blades one at a time.
Note
Do not throw away the foil frame.
