8 - ENGLISH
<When using the ET-D75LE90 / ET-D75LE95
lens>
The lock screw of the peripheral focus adjustment
ring may come into contact with lens xing brackets
(B) during focus adjustment, preventing you from
adjusting to the optimal focus. In such cases,
reattach lens xing brackets (B) in the positions for
lens xing brackets (A).
When attaching the lens xing brackets (B), attach
the spring washers and then the at washers to the
thumbscrews before attaching them to the unit.
Safely store the removed lens xing brackets (A),
thumbscrews, spring washers, and at washers so
as not to lose them.
Note
z
When this product is attached, the projector's
active focus optimizer function may not operate
properly. In such cases, do not press the lens
xing brackets onto the projection lens with
excessive force.
Flat washer
Spring washer
Lens xing
bracket (B)
Thumbscrew
Attaching (continued)
