11
Ref. No. 1E Procedure 1A  1B  1C  1D  1E Removal of Motor assembly.
1. Separate the motor assembly from the driving shaft assembly.
2. Take out the motor rotor assembly from the motor stator.
NOTE:
Make sure not to damage the magnet by motor rotor.
NOTE:
Make sure not to scratch FET circuit by motor rotor.
