Basic Instructions
2 − 12
Outline OR: Connects Form A (normally open) contacts in parallel.
OR/: Connects Form B (normally closed) contacts in parallel.
4
Program example
Ladder
Diagram
Boolean
Ladder Diagram
Address Instruction
X0 Y10
0
OR
X2
2
OR Not
X1
0
1
0
1
2
3
ST X 0
OR X 1
OR/ X 2
OT Y 10
Operands
Instruction
Relay
Timer/Counter
Contact
Index
modifier
Instruction
X Y R
L
(*1)
P
(*2)
E
(*3)
T C
mo
difi
er
(*4)
OR, OR/ A A A A A A A A A
(*1) This cannot be used with the FP0/FP−e.
(*2) This can be used only with the FP2/FP2SH/FP10SH.
(*3) This can be used only with the FP2SH/FP10SH.
(*4) This can be used only with the FP0R/FP2/FP2SH/FP10SH.
Explanation of example
Y10 goes on when either X0 or X1 turns on or X2 turns off.
X0
X1
X2
Y10
on
off
on
off
on
off
on
off
Description
Performs a logical OR operation with the results of the immediately preceding operation connected in
parallel.
OR
OR/
OR
OR Not
A
:
A
vailable
N/A: Not Available
