Basic Instructions
2 − 13
Precautions during programming
Use the OR instruction when normally open contacts (Form A contacts) are connected in parallel.
Use the OR/ instruction when normally closed contacts (Form B contacts) are connected in parallel.
The OR instruction starts from the bus line.
The OR and OR/ instructions can be used consecutively.
X2
Y10
X0
X1
X3
