High−level Instructions
3 − 14
Outline Inverts 32-bit data and transfers it to the specified 32-bit area.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P3 (PDMV/)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F3 DMV/ , DT11 , DT 20
S
D
Trigger
R0
10
11
ST R 0
F3 (DMV/)
DT 11
DT 20
S 32-bit equivalent constant or lower 16-bit area of 32-bit data to be inverted
(source)
D Lower 16-bit area of 32-bit data (destination)
Operands
modifier
S A A A A A A A A A A N/A A A A
D N/A A A A A A A A A A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F3
P3
32-bit data invert and move
(DMV/)
(PDMV/)
A: Available
N/A: Not Available
To Next Page
