Panasonic FP-E - Page 295

High−level Instructions
3 − 31
Outline Copies the specified 16-bit data to a block with one or more 16-bit
areas.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instructions
are not available.
Program example
Ladder
Diagram
Boolean
Ladder Diagram
Address Instruction
10
F11 COPY , DT 1 , DT10 , DT14
S
D2
Trigger
D1
R0
10
11
ST R 0
F 11 (COPY)
DT 1
DT 10
DT 14
S 16-bit equivalent constant or 16-bit area (source)
D1 Starting 16-bit area (destination)
D2 Ending 16-bit area (destination)
Operands
Operand
Relay Timer/Counter Register
Index
register
Constant
Inde
x
Operand
WX WY WR
WL
(*1)
SV EV DT
LD
(*1)
FL
(*2)
IX
(*3)
IY
(*4)
K H
Index
modifier
S A A A A A A A A A A A A A A
D1 N/A A A A A A A A A N/A N/A N/A N/A A
D2 N/A A A A A A A A A N/A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F11
P11
Block copy
(COPY)
(PCOPY)
A: Available
N/A: Not Available
