High−level Instructions
3 − 50
Explanation of example
The contents of data register DT10 and data register DT22 are exchanged when trigger R0 turns on.
DT20
DT21
DT22
DT23
DT24
K21K11
K10
K12
[D1] DT10
DT11
DT12
DT13
DT14
K20
K22
DT20
DT21
DT22
DT23
DT24
R0: on “F15 (XCH)” execution
K23
K13
K14 K24
K21
K11
K22
K12
[D1] DT10
DT11
DT12
DT13
DT14
K20
K10
K23K13
K14 K24
[D2]
[D2]
Description
The contents in the 16-bit areas specified by D1 and D2 are exchanged.
Flag conditions
・Error flag (R9007): Turns on and stays on when the area specified using the index modifier
exceeds the limit.
・Error flag (R9008): Turns on for an instant when the area specified using the index modifier
exceeds the limit.
