Outline Exchanges two 32-bit data items.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instructions
are not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F16 DXCH , DT 10 , DT22
D1
D2
Trigger
R0
10
11
ST R 0
F 16 (DXCH)
DT 10
DT 22
D1 Lower 16-bit area of 32-bit data to be exchanged
D2 Lower 16-bit area of 32-bit data to be exchanged
Operands
modifier
D1 N/A A A A A A A A A A N/A N/A N/A A
D2 N/A A A A A A A A A A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F16
P16
32-bit data exchange
(DXCH)
(PDXCH)
A: Available
N/A: Not Available
