High−level Instructions
3 − 200
Outline Copies the sign bit of the specified 16-bit data to all the bits of the
higher 16-bit area (extended 16-bit area).
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P89 (PEXT)” is not available.
Program example
Ladder
Diagram
Boolean
Ladder Diagram
Address Instruction
10
F89 EXT , DT 0
D
Trigger
R20
10
11
ST R 20
F 89 (EXT)
DT 0
D 16-bit area for storing original 16-bit binary data
Operands
Operand
Relay Timer/Counter Register
Index
register
Constant
Inde
x
Operand
WX WY WR
WL
(*1)
SV EV DT
LD
(*1)
FL
(*2)
IX
(*3)
IY K H
Index
modifier
D N/A A A A A A A A A A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
F89
P89
(PEXT)
(EXT)
16-bit data sign extension
A: Available
N/A: Not Available
