High−level Instructions
3 − 210
How to specify control data “n”
n specifies the starting bit position of destination data and the number of bits to be decoded using
hexadecimal data.
Number of bits to be encoded
(set range: H1 to H8)
Starting bit position of destina-
tion data to be encoded
(set range: H0 to HF)
Set value
Number of
bits
2H1
4H2
8 (1 byte)H3
16 (1 word)H4
32 (2 words)H5
64 (4 words)H6
128 (8 words)H7
256 (16 words)H8
Set value
Starting bit
position
H0 0
H1 1
H2 2
H3 3
H4 4
H5 5
H6 6
H7 7
H8 8
H9 9
HA 10
HB 11
HC 12
HD 13
HE 14
HF 15
The bits of “−” mark are invalid.
16-bit data
········ ·
15 12 11
000
8
0
743
00
0
Bit position
n
———— ————
00
