High−level Instructions
3 − 214
Outline Divides the specified 16-bit data into four 4-bit units and distributes the
divided data into the lower 4 bits of the specified 16-bit areas.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P94 (PDIST)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F94 DIST, DT10, K 4 , DT20
S
D
Trigger
R20
n
10
11
ST R 20
F94 (DIST)
DT 10
K4
DT 20
S 16-bit equivalent constant or 16-bit area to be divided (source)
n 16-bit equivalent constant or 16-bit area to specify number of data to be divided
D Starting 16-bit area for storing divided data (destination)
Operands
modifier
S A A A A A A A A A A A A A A
n A A A A A A A A A A A A A A
D N/A A A A A A A A A N/A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F94
P94
(PDIST)
(DIST)
16-bit data distribute
A: Available
N/A: Not Available
To Next Page
