High−level Instructions
3 − 222
Outline Searches for a specified value in a block of 32-bit areas.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P97 (PDSRC)” is not available.
Program example
Ladder
Diagram
Boolean
Ladder Diagram
Address Instruction
S2S1
Trigger
S3
F97 DSRC, DT10, DT20, DT 4010
R0
10
11
ST R 0
F97 (DSRC)
DT 10
DT 20
DT 40
S1 32-bit equivalent constant or 32-bit area to store the searched value in
S2 Starting 32-bit area of the block
S3 Ending 32-bit area of the block
Operands
Operand
Relay Timer/Counter Register
Index
register
Constant
Inde
x
Inte
g
er
Operand
WX WY WR WL SV EV DT LD
FL
(*1)
I K H
Index
modifier
Integer
device
S1 A A A A A A A A A A A A A N/A
S2 N/A A A A A A A A A N/A N/A N/A A N/A
S3 N/A A A A A A A A A N/A N/A N/A A N/A
(*1) This cannot be used with the FP0R, FPΣ and FP−X.
F97
P97
(PDSRC)
(DSRC)
32-bit data search
A
:
A
vailable
N/A: Not Available
