High−level Instructions
3 − 260
Outline Writes data to the FIFO buffer.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P117 (PFIFW)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
F117 FIFW, DT 110, DT 010
R10
DF
D
S
Trigger
10
11
12
ST R 10
DF
F117 (FIFW)
DT 110
DT 0
S 16-bit equivalent constant or 16−bit area for storing data to write in FIFO buffer
D Starting 16-bit area of FIFO buffer
Operands
modifier
S A A A A A A A A A A A A A A
D N/A A A A A A A A A N/A N/A N/A N/A A
(*1) This cannot be used with the FP0R, FPΣ and FP−X.
(*2) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F117
P117
(PFIFW)
(FIFW)
Data write to FIFO buffer
A: Available
N/A: Not Available
To Next Page
