Panasonic FV-0511VHL1

English
6
1
1
1
1
Operating
and
Installation
instructions
Self-drilling
Switch label
screw
Warranty
sheet
Part name Part nameAppearance Quantity
Grille
4
1
Flex-Z Fast™
bracket
(with 4 tapping
screws
-ST4.2X20)
1
Appearance Quantity
Unpack and carefully remove the fan heater from the packaging.
Refer to the Supplied Accessories list to verify that all parts are present.
Heater Performance:
This fan heater, WhisperWarm uses a PTC (Positive Temperature Coefficient) heater. This is a quick
and efficient means to warm up a bathroom.
Duct length, elbows and other factors increase static pressure which can hinder the performance
of most ventilation fans. WhisperWarm
fan heaters utilize Smart Flow microchip technology
that monitors the static pressure in the system and speeds up or slows down the rpm of the fan
depending upon the amount of resistance within the ducts. This feature allows the fan to perform
as rated and avoid potential installation issues.
Pick-A-Flow™ Feature (Ventilating mode only)
WhisperWarm fan heaters come with Pick-A-Flow™ speed options.
The Pick-A-Flow™ switch on the face of WhisperWarm fan allows
the option to choose 50 – 80 – 110 CFM, and WhisperWarm fan
heaters run constantly at the chosen air volume.
(Factory setting is 80 CFM)
Outstanding Energy Savings:
WhisperWarm
fan heaters are built using DC motor technology.
The DC motor for ventilating is 30 % - 70 % more energy
efficient than a traditional AC motor.
Optimum Ventilation Performance:
SUPPLIED ACCESSORIES
FV-0511VHL1
FV-0511VH1
R
R
R
FEATURES
UNPACKING
FOR MODEL FV-0511VH1
FOR MODEL FV-0511VHL1
Heat
Chaleur
Ventilation
Lumière
Veilleuse
Vent
Light
Night-Light
POUR LE MODÈLE FV-0511VH1
POUR LE MODÈLE FV-0511VHL1
Pick-A-Flow™
switch
R
R
R
