A&W Food Services of Canada Inc.
English Touch Screen Cable Kit Guide V970 2.2.docx QSR Solutions Page 6
Runner/Burger
Chute
Grill
Fryer
V
ideo Splitter
Equipment may be installed in different locations that are shown here. Please refer to your building plans for exact
system configuration and equipment placement.
** IMPORTANT NOTE **
 The CAT5 BLACK cable is for the video monitors
E-Pic Video
Controller
Bump Bar
CAT5 Black Video Cable
CAT5 White Bump Bar
Cable
30’Audio Cable
The Video Splitter and E-Pic Video
Controller are usually located above the
Manager’s desk on the top shelf or on the
to
p
of the cabinet.
Diagram #1b – Kitchen Video Subsystem
