A&W Food Services of Canada Inc.
English Touch Screen Cable Kit Guide V970 2.2.docx QSR Solutions Page 8
Network Rack Port Assignment
Device/Equipment IP
24 Port
Switch Router
KEYSTONE 48PORT
CUT OUT PANEL
ADSL or Cable Modem - - WAN
Back Office PC 192.168.11.11 N/A Port #1 Port #10
Touch Screen Terminal #1 192.168.11.81 Port #1 N/A Port #1
Touch Screen Terminal #2 192.168.11.82 Port #2 N/A Port #2
Touch Screen Terminal #3 192.168.11.83 Port #3 N/A Port #3
Touch Screen Terminal #4 192.168.11.84 Port #4 N/A Port #4
Touch Screen Terminal #5 192.168.11.85 Port #5 N/A Port #5
Touch Screen Terminal #6 192.168.11.86 Port #6 N/A Port #6
Delphi Drive-Thru OCB 192.168.11.71 Port #7 N/A Port #7
TM 88IV IP printer 192.168.11.72 Port #8 N/A Port #8
Time Shark 192.168.11.73
Port #9 N/A Port #9
E-pic Video Controller #1 192.168.11.90 Port #10 N/A N/A
Digital Menu Board #1 Dynamic Port #11 N/A Port #11
Digital Menu Board #2 Dynamic Port #12 N/A Port #12
Digital Menu Board #3 Dynamic Port #13 N/A Port #13
Digital Menu Board #4 Dynamic Port #14 N/A Port #14
Digital Menu Board #5 Dynamic Port #15 N/A Port #15
Digital Road Sign Dynamic Port #16 N/A Port #16
HME Wireless Base Station Dynamic Port #17 N/A Port #17
HME Timer Dynamic Port #18 N/A Port #18
Music System Dynamic Port #19 N/A Port #19
Meraki WiFi Router Dynamic Port #20 N/A Port #20
CCTV DVR/NVR Dynamic Port #21 N/A Port #21
A&W TV Dynamic Port #22 N/A Port #22
TBA TBA Port #23 N/A Port #23
Router 192.168.11.1 Port #24 Port #2 N/A
